Power 1R0 VAR GT
Control panel for 1 three-phase 230V AC motor. Power stage through frequency converter, allowing the speed to be regulated, as well as programming acceleration and deceleration ramps. Compatible with RS485 format absolute encoder. Display for selection of options and communication of door status. “Green Touch” system: APP to configure the panel with a mobile phone….
Dual 2H4 Plus
Control panel for 1 or 2 motors at 230 or 120V AC, depending on the model. Integrated radio receiver. It allows the programming of the phase shift times between leaves, opening and closing maneuvers, as well as the soft stop times at the end of each maneuver. Engine force regulation. Electro-lock or magnetic retainer. Second…
Power 1R0
Control panel for 1 motor 230V AC single-phase or three-phase or 380V AC three-phase. Power stage by industrial contactors. Available with magnetic motor circuit breaker. Compatible with absolute encoder RS485 format. Supports SRT and SRT MN: plug-in radio receiver card Wirelessband SRT BAND: plug-in receiver card DMT: magnetic loop detector plug-in card
Power 1R0 VAR
Control panel for 1 three-phase 230V AC motor. Power stage using a frequency converter, allowing the speed to be regulated, as well as the programming of acceleration and deceleration ramps. Compatible with RS485 format absolute encoder. Supports – SRT and SRT MN radio receiving card – Wirelessband SRT BAND receiving card – DMT magnetic loop…
Power 1R0 GT
Control panel for 1 motor at 230V AC single-phase, three-phase or 380V AC three-phase. Power stage using industrial contactors. Version available with thermal motor protector. Compatible with RS485 format absolute encoder. Display for selection of options and communication of door status. “Green Touch” system: APP to configure the panel with a mobile phone. NFC reader…
Power Ramp GT
Combined control panel for dock leveler and door. Power stage by industrial contactors, with integrated motor circuit breaker with current control.Selection of options via microswitch or Green Touch APP: NFC (Android)or Bluetooth LE (IOS Android).Dock levelers or lifting tables: three-phase 380V AC hydraulic motor. 1electro-valve (available up to 4 with plug-in external cards). 2 limit…
